Die locking force

20000 KN

Space between tie bars

1350*1350 MM

Tie bar diameter

Φ 280 MM

Die thickness(Min-Max)

650~1600 MM

Locking stroke

1400 MM

Ejection stroke

300 MM

Ejection force

650 KN

Injection force

1500 KN

Injection position

0 、 -350 MM

Plunger diameter

130 MM    150 160 MM

140 MM
170 MM

Injection weight

24.5 KG
32.7  37.3KG

28.5 KG
42.1 KG

Casting pressure (Intensifg.)

113 Mpa
84  74Mpa

97 Mpa
66 Mpa

Casting area

1769 CM²
2380 2702CM²

2061 CM²
3030 CM²

Max.Casting area (40Mpa)

5000 CM²

Plunger penetration

400 MM

Casting flange diameter

Φ260 MM

Height of pressure chamber flange

30 MM

Injection stroke

960 MM

Dry cycle

25 S

System working pressure

14 Mpa

Motor power

55*2 KW

Oil tank capacity

3500 L

Machine weight

135000 KG

Machine dimensions(L*W*H)

13.7*4.7*4.9 M
