  Home >> Products >> Cold Forging Machine >> One die two blow cold forging machine >> All
· SJH0432
· SJH0565
· SJH06102
· SJH06120
· SJH0676
· SJH0880
· SJH10150
· SJH10165

SJH0880
Max makable dia φ8MM
Max makable length 82MM
Slide stroke 140MM
Speed range 70-90PCS/MIN
Main die size φ55×98mm
Rough punch size φ38×128mm
Fine punch size φ38×128mm
Cut-off-die size φ32×40mm
Cut-off-die size 14×40×96mm
Main motor 7.5kw
Oil pump 1/4HP(180W)
Net weight 3750kg
Volume 3070×1250×1350mm
