  Home >> Products >> Cold Forging Machine >> One die two blow cold forging machine >> All
· SJH0432
· SJH0565
· SJH06102
· SJH06120
· SJH0676
· SJH0880
· SJH10150
· SJH10165

SJH10150
Max makable dia 9mm
Max makable length 150mm
Slide stroke 220MM
Speed range 48-60pcs/min
Main die size Φ65×168mm
Rough punch size φ48×150mm
Fine punch size φ40×150mm
Cut-off-die size φ32×44mm
Cut-off-die size 14×50×100mm
Main motor 7.5kw
Oil pump 1/2HP（370w)
Net weight 5150Kg
Volume 4400×1600×1600mm
