Forging station
6 NO.
Forging force
30,000 KGS
Max cut-off dia.
Ф7 MM
Max cut-off length
55 MM
Speed range
180 PCS/MIN
P.K.O stroke
10 MM
K.O.Stroke
50 MM
Main slide stroke
100 MM
Main moto
11 KW
Cut-off-die size
Ф24*30L MM
Punch die size
Ф32*90L MM
Main die size
Ф38*100L MM
Die pitch
48 MM
Machine dimension(L*W*H)
260*180*130 CM
Machine weight(Approx)
8,800 KGS
Max forging dia. on head
Ф12 MM
Normal bolt size
2-4 MM
Shank length of blank
10-50 MM
