Forging station

4 NO.

Forging force

220,000 KGS

Max cut-off dia.

Φ 23 MM

Max cut-off length

510 MM

Speed range

35-50 PCS/MIN

P.K.O Stroke

60 MM

K.O.Stroke

510 MM

Main slide stroke

670 MM

Main motor

75 KW

Cut-off-die size

Φ 74* 120L MM

Punch die size

Φ 75* 250L MM

Main die size

Φ 100* 510L MM

Die pitch

120 MM

Machine dimension(L*W*H)

1000*320*340 CM

Machine weight(Approx)

80,000 KGS

Normal bolt size

12-20 MM

Shank length of blank

150-490 MM
